H40-70A Series IC Forklifts Lift 4K to 7K Pounds

Sept. 22, 2023
Hyster's model A series of IC forklifts offer a lifting capacity of 4,000 to 7,000 lb. and provide the Dynamic Stability System (DSS) for optimal safety.

Hyster Company releases the first models built on its all-new A Series platform, the Hyster H40-70A series. These 4,000 to 7,000-lb. (1,814 to 3,175 kg) capacity lift trucks offer ergonomics, low TCO, and safety features designed to bolster confidence and productivity, including the innovative Dynamic Stability System (DSS).



The A Series is a line of forklift trucks manufactured using the company's A+ Logic design philosophy. A+ Logic is a scalable approach that begins with the strong base of the A Series truck platform and allows customers to choose the options they need from a fully integrated set of scalable and adjustable features based on their unique application.



Standard on all H40-70A models and completely maintenance-free, DSS uses sensors to continually monitor truck status. When it detects the truck exceeding designated thresholds, DSS automatically implements measures like limiting truck speed and hydraulic function, to help minimize the risk of forward and sideways tip-overs. It gives visual indicators, audible alerts, and automatic performance adjustments for stable travel.



The operator compartment enables easy entry and exit with a lowered seat, increased floor space, and generous head and shoulder clearance. A low dash and wide mast design provide excellent forward visibility, and an optional high-strength laminated glass roof offers an unobstructed upward view to help operators place loads at height.

  • Dynamic Stability System (DSS)
  • Operator-Centric Design
  • Exceptional Forklift Visibility
  • Keep Costs Under Control
  • Operator Assistance Systems

Applications:

  • Building materials
  • Metals
  • Lumber
  • Chemicals & plastics
  • Agriculture
  • Mining, energy & construction
  • Retail & e-Commerce
  • 3PL
ModelH40AH50AH60AH70ALoad Capacity 4,000 lb. (1,814 kg)  5,000 lb. (2,268 kg)  6,000 lb. (2,722 kg) 7,000 lb. (3,175 kg)Load Center24 in. (610 mm)Lift Height200 in. (5 m) Turning Radius 86899496Width46 to 50 in. (1,168 to 1,270 mm)47 to 53 in. (1,194 to 1,346 mm)Weight7,600 lb. (3,447 kg)8,430 lb. (3,824 kg)9,890 lb (4,486 kg). 10,680 lb. (4,844 kg) Engine TypeYanmar 2.1 L Diesel/Yanmar 2.2 L LPGTransmissionPowershift 1-speed/Duramatch
