Interactive PDF version of the new 2010 catalog offers Tech-Etch’s standard and custom EMI/RFI shielding product line in an easy-to-use format that lets the viewer jump from page to page with a click of the mouse and even download sales drawings of selected products. The Table of Contents, Part Number Directory, as well as all internal page number references are clickable. The 52-page catalog features to-scale technical drawings, compression values and metal thickness for over 100 BeCu and stainless steel finger stock shielding profiles. Interactive PDF sales drawings of every profile can be downloaded with a mouse click. For ease of use, profiles are organized by mounting option and arranged by ascending gap Free Height size to help the design engineer locate the proper gasket. Once located the corresponding interactive PDF sales drawing is just a click away. Interactive PDF sales drawings for Metalized Gasket profiles, Fan Vents and one- and two-piece board level shields are also clickable for download. Contact rings, “D” connector gaskets, knitted mesh shielding, elastomer gaskets, filters, and honeycomb vents are offered. Information on material compatibility and specifications, plus compression and attenuation management make this interactive shielding catalog a must for the design engineer.
