Banana Jack; Banana Jack; 15 A; Black; Beryllium Copper; 5000 Vrms (Max.)

Standard Banana Jack, Solderless and Stackable, 5000 VRMS (Max.), 15 A, +122 °FBanana Jack, 15A, Nickel Plated with ABS Insulation, Black

Designed to fit on the end of any 22AWG to 18AWG wire

Cross hole wire entry fits up to .12"" (3mm) diameter

Available with tarnish resistant nickel or gold plating for very low contact resistance

Set screw simplifies assembly of test leads and jumpers by using a flat balde screwdrive

Fits standard panel and binding post banana jacks .161"" to .166"" (4.00mm to 4.2mm) diameter
Ratings:
Voltage: Hands free testing in controlled voltage environments: 5000Vrms Max. For CE Compliance: not intended for hand held use at voltages above 33Vrms/70Vdc
Current: 15 Amps
Maximum Operating Temperature: +122°F (+50°C)
Materials
Banana Jack: Beryllium Copper, Gold Plated
Banana Plug Body - Brass, Nickel Plated
Spring Beryllium Copper, Nickel Plated
Insulation: ABS
Set Screw: Steel, Zinc Plated, 8-32 Single Slot

Mounting Type: Panel  |  Termination: Screw  |  Material, Contact: Beryllium Copper  |  Width: 0.44in.  |  Contact Plating: Nickel  |  Wire, AWG: 22-18  |  Insulation Material: ABS (Model 4899 Polyphenylene Sulfide)  |  Current, Rating: 15A  |  Insulation Type: Insulated  |  Type: Jack/Plug  |  Length, Terminal: 0.55in.  |  Color: Black  |  Material, Body: Brass  |  Voltage, Rating: 5000 V (Hand Free), 33 V/70 VDC (Hand Held)  |  Diameter, Terminal: 0.166in.  |  Brand/Series: 1825 Series  |  Temperature, Operating, Maximum: +122°F  |  Diameter, Mounting Hole: 0.12"  |  Primary Type: Banana  |  Height: 1.55in.  |  Material, Spring: Beryllium Copper
