Powerpole® Housing Finger Proof ConnectorsPowerPole Modular Connector, Housing, 15/45 amp Housing with Spring, Red
Powerpole® connector modules feature a single pole, genderless connector half. This module consists of a color-coded housing. The module is designed to mate with another identical module. The housing is durable, high-impact resistant polycarbonate, with a flammability rating of UL94 V-0. An internal stainless steel leaf spring forces contacts to maintain constant pressure. The contacts are sold separately and are made from highly conductive silver-plated copper. UL recognized file No. E26226. CSA certified file No. LR25154.0.32" × 0.32" × 0.97" Housing 1.63" Length for a Mated Set Dielectric Voltage: 2200VDC?VAC | Type: PP15/45 Housing | Color, Housing: Red | Diameter, Insulation, Wire: 0.6in. | Brand/Series: Powerpole, PP15/45 | Flammability Rating: UL94 V-0 | Temperature Range: -20 to +105°C | Primary Type: High Current |
Powerpole® connector modules feature a single pole, genderless connector half. This module consists of a color-coded housing. The module is designed to mate with another identical module. The housing is durable, high-impact resistant polycarbonate, with a flammability rating of UL94 V-0. An internal stainless steel leaf spring forces contacts to maintain constant pressure. The contacts are sold separately and are made from highly conductive silver-plated copper. UL recognized file No. E26226. CSA certified file No. LR25154.
