Powered by compressed air, the Syphon Spray System is a cost-effective alternative to hiring expensive sanitizing services. Ideal for industrial facilities with in-plant air compressors, the Syphon Spray System provides wide-area spray capability to thoroughly disinfect floors, walls, and workbenches, as well as tools, machinery, and equipment.



Featuring a 12-in. (30.5 cm) Syphon Spray Gun, the Syphon Spray System delivers up to 16 gallons (60.5 L) of liquid per hour. Adjustable nozzle tip controls flow and spray pattern from a steady stream to a light mist. Rugged 20-gallon (75.7 L) steel canister stores cleaning solutions with a secure lid to avoid spillage while rolling.



The easy-to-maneuver Syphon Spray System is dolly-mounted and comes complete with a push handle. Reach remote locations with 20 ft (6 m) syphon hose assembly. All components are suitable for use with common, non-corrosive, disinfecting solutions.

  • Versatile Syphon Spray Gun with 12 in. (30.5 cm) aluminum extension and adjustable brass nozzle
  • Heavy-duty, chemical-resistant 20-gallon (75.7 L) drum
  • Removable lid with locking ring
  • 20-ft (6 m) syphon hose assembly to reach remote locations
  • 3/8 in. (9.53 mm) NPT inlet with 1/4 in. (6.35 mm) Industrial Interchange plug
  • Rugged, durable construction with Syphon Spray Gun and hose storage
Part
Number
Air Inlet
FNPT
Min.
Compressor
Required
FlowSyphon
Flow Rate
Dimensions
(L x W x H)
Weight
SS20203/8 in. (9.53 mm)2 hp9 cfm16 gph27 x 20.8 x 35.5 in.
(68.5 x 52.8 x 90.2 cm)
39.6 lb. (18 kg)
