Easybend Lineset Bender

Aug. 11, 2021
Easybend from MarketAir is a quick, easy, and safe soft copper pipe bender for preventing costly HVAC/R lineset kinking.

A 26-ft-long extended lineset bending kit offers a quick, easy, and reliable mandrel-type, soft copper refrigeration lineset bender for the U.S. and Canadian markets.



Like the original 13-ft kit, the extended 26-ft easybend kit includes mandrels for the four lineset sizes commonly used in ductless and VRF/VRV installations: 1/4 (4), 3/8 (6), 1/2 (9), and 5/8-in. (12 mm) (O.D.). The 26-ft mandrels permit the installer easy passage through walls and around obstacles. The mandrels also enable multiple compound bends without kinking 25-ft linesets.



Another easybend addition is a 3/4-in. (19 mm) (O.D.) mandrel that’s color-coded white and is available only in a 13-ft (4 m) length. It was developed specifically from contractor requests for a bending mandrel that accommodates larger lineset suction lines commonly used in ducted a/c systems. It’s sold separately from the original easybend mandrel kit.



All solid polyethylene easybend mandrels prevent linesets from collapsing and/or kinking during bending and permits any lineset configuration without insulation removal, replacement, and refastening. Additionally, easybend allows simultaneous bending of both copper lines, resulting in a more expedient, accurate, and attractive installation.

  • Prevents kinks that often go unnoticed in concealed walls or under insulation, which can subsequently restrict refrigerant flow or cooling capacity and ultimately develop refrigerant-leaking leaks
  • Maintains job expediency and system efficiency from insulation cutting, removing, replacement, and resealing
  • Pays back immediately when considering installation time, materials, and labor required to repair a kinked lineset
  • One-year warranty
  • Suitable for use between 14° and 113°F (-10° and 45°C).
