Sullins 2012 Catalog details 20 series of Sullins and Micro Plastics board-to-board, board-to-cable and wire-to-board connectors. Offered to complement Sullins' Catalog 2.0, the 168-page literature features comprehensive data on the company's standard, high-density, and high-temperature card edge connectors, along with headers and shunts/jumpers, and IDC sockets and DIP plugs. Furthermore included in the catalog are datasheets containing all the product information, photos, technical drawings, electrical and mechanical specifications design engineers and purchasing professionals require to source the interconnects that best suit their application.
Highlighted in The Sullins 2012 Catalog is extensive information pertaining to standard and custom high-density, high-temperature, bi-level, male and female card edge connectors in profiles ranging from 10.25 mm (0.404") to 23.23 mm (0.915"). Of special note are Sullins' new dual-edge 0.100" (2.54 mm) contact center parts. Sullins and Micro Plastics card edge connectors are available with standard operating temperatures ranging from -65 degrees C to +150 degrees C, or custom ordered with operating temperatures to +250 degrees C. RoHS-compliant lead-free (nickel underplate) plating options and readouts are detailed. Contact centers included are 1.00 mm (.039"), 0.050" (1.27 mm), 0.078" (1.98 mm), 0.100" (2.54 mm), 0.125" (3.18 mm), 0.150" (3.84 mm) and 0.156" (3.96 mm). Among the mounting style options provided are clearance holes, flush mounting, threaded inserts, straddle mount, floating bobbin, side mounting and open card slot. Termination types are comprised of card extender, dip solder (straight or right angle), eyelet, press fit, surface mount, wire wrap, bi-level, and male card edge in card extender, dip solder (straight or right angle) or dual edge for no solder application. Parts are supplied in a variety of contact positions to facilitate design flexibility and manufacturing efficiencies. Male (shrouded box and breakaway) and female headers and jumpers are also covered in 1.00 mm (0.039"), 0.050" (1.27 mm), 2 mm (0.079") and 0.100" (2.54 mm) contact centers.
