The new Konecranes CLX Electric Chain Hoist is targeted for manufacturing applications where high-speed load transfers and precise assembly work are required. Currently in capacities of 60 to 2,000 kg (130 to 4,400lbs) CLX can be paired with workstation cranes, overhead cranes and jibcranes or deployed in an endless variety of fixed configurations. Larger capacities up to 5,000 kg (11,000 lbs) will be available soon. A number of improvements have been incorporated into the CLX over Konecranes' previous models and over competing brands. The new robust aluminium frame is accompanied by a maintenance-free transmission and patented five-tooth chain sprocket with intermediate teeth which provides quiet operation and longer chain life. The latest oil lubrication-based transmission lowers operating temperature, enabling increased power. An available speed ratio of 6:1 enables movements that are fast 25% faster than its predecessor and precise, with corresponding improvement in work cycles. Safety and maintenance features of CLX from Konecranes have also been improved to promote safe operations and a longer service life. All electronics have been placed on compact circuit boards, decreasing internal wiring and limiting the number of parts and time required for maintenance. Additional safety functions have been integrated into the hoist's construction. For example, the new slip clutch is easy to adjust and is designed to hold the load in an unlikely event of clutch failure and the new magnetic brake is designed so that no adjustments are required over the life of the brake.
- speed ratio of 6:1
- capacities of 60 to 2,000 kg
