VIDAR Smart Speed Motor Reduces Size, Energy to Improve Industrial Operations

VIDAR is a new type of motor launched by VIDAR, an ITT, Inc. company, that embeds variable-speed intelligence into the motor to improve operations in pumps, fans, and fluid process systems. By doing so, it removes the need for mechanical controls, such as throttled valves or dampers. Lowering energy usage and CO₂ emissions by only using the exact amount of energy needed for a task, VIDAR reduces costs, increases equipment lifespan, and improves process controls.

Its patented AC-Link technology replaces the usual AC-to-DC-to-AC variable frequency drive (VFD) technology with a streamlined AC-to-AC approach. By removing the DC stage, bulky capacitors are eliminated, enabling the motor and VFD to be combined into a single device. This compact design allows VIDAR to easily fit into the size of a standard motor while eliminating special wiring, enclosures, or extra space.

Its precise motor speed control also ensures consistent flow rates, improves product quality, and adapts to changing workloads for flexibility and scalability.

Built for industrial facilities, it uses a high-efficiency synchronous reluctance magnet-assisted motor designed using IEEE-841 specifications, meets CSA Class 1 Division 2 for hazardous areas, and meets IEEE-519 power quality standards.

Features:

• 15 to 75 hp at 460 V
• Speeds up to 4,500 rpm
• Installs into the footprint of a conventional NEMA motor
• Direct AC-to-AC power conversion
• No electrolytic capacitors needed
• Singling cooling fan for the converter and motor
• Synchronous Reluctance Magnet-Assisted
• Exceeds NEMA premium efficiency standards
• Meets IEEE-519 standards
• Designed using IEEE-841 specifications
• Rated for Class I, Division 2,  environments
• Compatible with PLCs, SCADA, and DCS systems
• Plug-in keyboard for programming
• Standard analog and digital I/O
• Standard ethernet IP/Modbus TCP
• Motor is combined with the VFD into one solution
• Reduces energy consumption and CO₂ emissions
• Eliminates wiring, enclosures, extra space, and mechanical controls
• Ensures consistent flow rates
• Modular design simplifies maintenance
• Adapts to variable demands
• Works in outdoor industrial environments

VIDAR | an ITT company
Syracuse, NY
(315) 234-1973
[email protected]
vidarmotors.com
