PI USA Catalog: PILine Ultrasonic Piezomotors (2015)

A catalog of ultrasonic piezo motors, stages, and positioners for precision motion and automation applications includes compact, high speed, or cost-effective customized OEM designs.

Ultrasonic piezo mechanisms are direct drive motors with self-locking properties. They cover a very large dynamic range with velocities from microns/second to 100s of millimeters/second. The ceramic nature makes them intrinsically vacuum compatible. Easily integrated into other components, piezo motors do not generate or are affected by magnetic fields, making them ideal for E-beam and electron Microscopy applications.

Standard positioners include thumbnail-sized miniature rotary stages, matchbox-sized linear stages, and large XY stages for applications such as scanning microscopy. In addition to the many standard products presented in the catalog, PI can quickly modify existing product designs or provide a fully customized OEM part to fit the exact requirements of the application.
